● Revolutionary AI-Powered EDA Platform

AI-Powered EDA Automation with Microservice Architecture

Get Started
Watch Demo
AI EDA Orchestration
U
"Run synthesis for des design using FreePDK45 technology with timing optimization"
AI
→ Analyzing request...
→ Design: des | Tech: FreePDK45
→ Loading FreePDK45 process library...
→ Strategy: Timing optimization
→ Setting optimization constraints...
→ Calling synthesis service on port 18001...
AI is orchestrating EDA tools...
set FINAL_VERILOG_OUTPUT_FILE "${TOP_NAME}.mapped.v"
set FINAL_SDC_OUTPUT_FILE "${TOP_NAME}.mapped.sdc"
set REPORTS_DIR "reports"
set RESULTS_DIR "results"

file mkdir ${REPORTS_DIR}
file mkdir ${RESULTS_DIR}

set_host_options -max_cores 4
set_app_var html_log_enable true
set_app_var compile_seqmap_propagate_constants true
set_app_var power_cg_auto_identify true
set_app_var hdlin_check_no_latch true

set_app_var target_library [concat $slow_db]
set_app_var link_library [concat * $slow_db $openram_db(slow)]

check_library
set_svf data/${TOP_NAME}.synthesis.svf
saif_map -start

define_design_lib WORK -path ./WORK
analyze -format ${FILE_FORMAT} -recursive -autoread $RTL_DIR -top ${TOP_NAME}
elaborate ${TOP_NAME}
current_design ${TOP_NAME}
link

create_clock -name $CLOCK_NAME -period $PERIOD [get_ports $CLOCK_NAME]

set_fix_multiple_port_nets -all -buffer_constants -feedthroughs [all_designs]
check_design -summary
check_timing

set_max_fanout $FANOUT_VALUE $TOP_NAME
set_max_transition $TRANSITION_VALUE $TOP_NAME
set_max_capacitance $CAPACITANCE_VALUE $TOP_NAME

set_dynamic_optimization $DYNAMIC_OPTIMIZATION
set_leakage_optimization $LEAKAGE_OPTIMIZATION

compile -map_effort $MAP_EFFORT -power_effort $POWER_EFFORT -area_effort $AREA_EFFORT

uniquify -force
change_names -rules verilog -hierarchy -verbose

report_qor > ${REPORTS_DIR}/qor.rpt
report_timing -max_paths 15 > ${REPORTS_DIR}/timing.rpt
report_area -nosplit > ${REPORTS_DIR}/area.rpt
report_power -nosplit > ${REPORTS_DIR}/power.rpt

write -format verilog -hierarchy -output ${RESULTS_DIR}/${FINAL_VERILOG_OUTPUT_FILE}
write_sdc -nosplit ${RESULTS_DIR}/${FINAL_SDC_OUTPUT_FILE}
write -format ddc -hierarchy -output ${RESULTS_DIR}/${TOP_NAME}.ddc

exit
N-gram Match
N-gram Match
Weighted N-gram
Weighted N-gram
Syntax Match
Syntax Match
Dataflow Match
Dataflow Match
4+
EDA Services
Unified microservices
RTL→GDSII
Complete Flow
End-to-end automation
Privacy
Intelligence
Local LLM
CodeBLEU
Evaluation
Academic-grade metrics
Core Capabilities

Powerful EDA Integration

Seamlessly bridge natural language with professional EDA tools through intelligent AI orchestration and unified microservice architecture.

Complete EDA Flow

End-to-end RTL-to-GDSII implementation with professional EDA tools. Seamlessly integrates synthesis and physical design through intelligent automation and natural language commands.

Design Compiler Cadence Innovus

Intelligent Workflow Orchestration

AI-powered automation for complete EDA workflows with intelligent stage coordination and parameter extraction. Natural language to GDSII orchestration with session management and context preservation.

Local LLM End-to-End Automation

Microservice Architecture

Scalable FastAPI-based microservices with independent deployment, health monitoring, and load balancing. Distributed system design enables fault isolation and horizontal scaling for high availability.

FastAPI Scalable

Academic Evaluation

Comprehensive CodeBLEU evaluation framework for measuring AI-generated code quality. Includes syntax matching, dataflow analysis, and semantic consistency metrics.

CodeBLEU Quality Metrics Research Grade
System Design

How It Works

Intelligent AI orchestration seamlessly bridges natural language with professional EDA tools through unified microservice architecture.

Language Input

Submit design requirements through conversational AI interface

AI Orchestration

AI agent analyzes requests, extracts parameters, and selects optimal tools

MCP
Protocol

Translate AI decisions into tool-specific commands through Model Context Protocol

Tool Execution

Execute professional EDA workflows using Synopsys, Cadence, and open-source tools

Synthesis Service

:18001
Online
• RTL to Gate-level Conversion • Area/Timing/Power Optimization • Design Compiler Integration

Placement Service

:18002
Online
• Intelligent Cell Placement • Density & Timing Optimization • Innovus Backend Integration

CTS Server

:18003
Online
• Clock Tree Synthesis • Skew & Latency Optimization • Timing Convergence

Route Server

:18004
Online
• Global & Detailed Routing • DRC/LVS Verification • GDSII Generation
Get Started

Quick Installation

Get up and running in minutes with our streamlined installation process. Follow these simple steps to set up AutoEDA's 4-server microservice architecture and start automating your EDA workflows.

01

Clone & Setup

Download AutoEDA repository and install Python dependencies

bash Terminal
# Clone the AutoEDA repository
git clone https://github.com/Duke-CEI-Center/AutoEDA.git
cd AutoEDA

# Create virtual environment
python3 -m venv venv
source venv/bin/activate  # Linux/Mac
# venv\Scripts\activate   # Windows

# Install dependencies
pip install -r requirements.txt
02

Verify Prerequisites

Check EDA tools and configure environment variables

bash Environment Setup
# Verify EDA tools (required)
dc_shell -version  # Synopsys Design Compiler
innovus -version   # Cadence Innovus
lmstat -a          # Check license servers

# Set environment variables
export OPENAI_API_KEY="your_openai_api_key_here"
export MCP_SERVER_HOST="http://localhost"
export LOG_ROOT="./logs"
03

Start Services

Launch the 4-server microservice architecture

bash Service Launch
# Start all 4 EDA microservices
python3 src/run_server.py --server all

# Services will run on:
# Synthesis:  http://localhost:18001
# Placement:  http://localhost:18002
# CTS:        http://localhost:18003
# Routing:    http://localhost:18004

# Start AI agent (new terminal)
python3 src/mcp_agent_client.py
04

Test Your First Design

Run a complete design flow with natural language

bash First Design
# Test synthesis with natural language
curl -X POST http://localhost:8000/agent \
  -H "Content-Type: application/json" \
  -d '{
    "user_query": "Run synthesis for design des with performance optimization",
    "session_id": "quickstart"
  }'

# Or try a complete RTL-to-GDSII flow
curl -X POST http://localhost:8000/agent \
  -d '{
    "user_query": "Run complete flow for design des",
    "session_id": "quickstart"
  }'
Our Team

About Us

Meet the dedicated research team behind AutoEDA, working at the intersection of AI and Electronic Design Automation. Our interdisciplinary team spans multiple institutions and brings together expertise in machine learning, hardware design, and software engineering to revolutionize EDA workflows.

Faculty Advisors

Yiran Chen

Yiran Chen

John Cocke Distinguished Professor

Duke University, Electrical & Computer Engineering

yiran.chen@duke.edu Profile
Ang Li

Ang Li

Assistant Professor

University of Maryland, Electrical & Computer Engineering

angliece@umd.edu Profile

Research Team

Yiyi Lu

Undergraduate Researcher

DKU & Duke University

Hoi Ian Au

Undergraduate Researcher

Tsinghua & Duke University

Junyao Zhang

ECE PhD Student

Duke University

Jingyu Pan

ECE PhD Student

Duke University

Yiting Wang

ECE PhD Student

University of Maryland

Jianyi Zhang

ECE PhD Student

Duke University

Call for Collaborations

We welcome collaborations from researchers, industry partners, and institutions interested in advancing AI-powered Electronic Design Automation. Whether you're working on EDA tools, machine learning applications, or hardware design, we'd love to explore potential partnerships and joint research opportunities.
